Cooler Master CMP 510 ATX Mid-Tower

Cooler Master CMP 510 ATX Mid-Tower with Mesh Intakes, ARGB Edge Strip, Tempered Glass Side Panel, Triple 120mm ARGB Lighting Fans



Model Number CP510-KGNN-S00

Exterior Color Black

Materials Steel, Plastic, Tempered Glass

Dimensions (L x W x H) 445 x 204 x 463mm (incl. Protrusions), 436 x 204 x 448mm (excl. Protrusions)

Volume 39.85L (exlc. Protrusions)

Motherboard Support Mini ITX, Micro ATX, ATX

Expansion Slots 7

2.5" / 3.5" Drive Bays (Combo) 2

2.5" Drive Bays 2

I/O Panel 1x USB 3.2 Gen 1 Type-A, 1x USB 2.0, 1x 3.5mm Headset Jack (Audio+Mic), 1x ARGB Controller

Pre-installed Fans - Front 3 x 120mm ARGB Fan (CP510-KGNN-S00)

Pre-installed Fans - Rear N/A

Fan Support - Top 2x 120mm, 2x 140mm

Fan Support - Front 3x 120mm, 2x 140mm

Fan Support - Rear 1x 120mm

Radiator Support - Top 120 / 240mm (Memory bar height limit 35mm, First assemble the memory and then assemble the Radiator)

Radiator Support - Front 120mm, 140mm, 240mm, 280mm

Radiator Support - Rear 120mm

Clearance - CPU Cooler 161mm

Clearance - PSU 160mm

Clearance - GFX 350mm (w/o front fans & radiator)

Cable Routing 18.5mm

Dust Filters Top, Bottom

Power Supply Support Bottom Mount, ATX

Series CMP Series

Size Mid Tower
