Name: Seasonic CORE-GC-650 Non-Modular PC Power Supply 80 PLUS Gold 650 Watts
Brand: Compumarts Egypt
SKU: seasonic-core-gc-650-non-modular-pc-power-supply-80plus-gold-650-watts
Availability: InStock

🎉 Up to 70% Off Selected ItemsShop Sale

Home Store

Seasonic CORE-GC-650 Non-Modular PC Power Supply 80 PLUS Gold 650 Watts

Subcategory	Power Supply
Brand	Seasonic
Model	CORE-GC-650
POWER OF SUPPLY POWER	650W
EFFICIENCY RATING	80+ Gold

Technical Specifications
80PLUS		Gold
Cybenetics Efficiency Level		TBA
Cybenetics Noise Level		TBA
Form Factor		Intel ATX 12 V
Dimensions		140 mm (L) x 150 mm (W) x 86 mm (H)
Fan Information	Fan Size	120 mm
	Fan Control	Smart and Silent Fan Control
	Fan Bearing	Sleeve Bearing
	Life Expectancy	25,000 hours at 40 °C, 15 % - 65 % RH
Cable Information	Modularity	Fixed cables
Cable Information	Cable type	Flat black cables
Electrical Features	Operating Temperature	0 - 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C)
	MTBF 25 °C, excl. fan	100,000 hours
	AC Input	Full Range
	Protection	OPP, OVP, OCP, OTP, SCP, UVP
Safety and Environmental	Safety and EMC	cTUVus, TUV, CB, CCC, BSMI, CE, FCC
Safety and Environmental	Environmental Compliance	Energy Star, RoHS, WEEE, ErP Lot 6, REACH

Power Output
AC Input	Voltage: 100 V - 240 V
	Current: 9 - 4.5 A
	Frequency: 50 Hz - 60 Hz
DC Output	Rail	+3.3 V	+5 V	+12 V	-12 V	+5 VSB
	Maximum Power	20 A	20 A	54 A	0.3 A	3 A
	Maximum Power	100 W		648 W	3.6 W	15 W
	Total continuous power	650 W

$38.15

Seasonic CORE-GC-650 Non-Modular PC Power Supply 80 PLUS Gold 650 Watts—

$38.15

Seasonic CORE-GC-650 Non-Modular PC Power Supply 80 PLUS Gold 650 Watts—

$38.15

Product Information

Shipping & Returns

Description

Seasonic CORE-GC-650 Non-Modular PC Power Supply 80 PLUS Gold 650 Watts

Subcategory	Power Supply
Brand	Seasonic
Model	CORE-GC-650
POWER OF SUPPLY POWER	650W
EFFICIENCY RATING	80+ Gold

Technical Specifications
80PLUS		Gold
Cybenetics Efficiency Level		TBA
Cybenetics Noise Level		TBA
Form Factor		Intel ATX 12 V
Dimensions		140 mm (L) x 150 mm (W) x 86 mm (H)
Fan Information	Fan Size	120 mm
	Fan Control	Smart and Silent Fan Control
	Fan Bearing	Sleeve Bearing
	Life Expectancy	25,000 hours at 40 °C, 15 % - 65 % RH
Cable Information	Modularity	Fixed cables
Cable Information	Cable type	Flat black cables
Electrical Features	Operating Temperature	0 - 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C)
	MTBF 25 °C, excl. fan	100,000 hours
	AC Input	Full Range
	Protection	OPP, OVP, OCP, OTP, SCP, UVP
Safety and Environmental	Safety and EMC	cTUVus, TUV, CB, CCC, BSMI, CE, FCC
Safety and Environmental	Environmental Compliance	Energy Star, RoHS, WEEE, ErP Lot 6, REACH

Power Output
AC Input	Voltage: 100 V - 240 V
	Current: 9 - 4.5 A
	Frequency: 50 Hz - 60 Hz
DC Output	Rail	+3.3 V	+5 V	+12 V	-12 V	+5 VSB
	Maximum Power	20 A	20 A	54 A	0.3 A	3 A
	Maximum Power	100 W		648 W	3.6 W	15 W
	Total continuous power	650 W
